6 Install four nuts (H) onto the four

mounting bracket screws, then tighten

the nuts with the hexagonal wrench (J).

7 Go to “Connecting the fan cable” on

page 13.

Installing the CPU cooler on an AMD

AM2/K8 (socket 745/939/940) CPU

To install the CPU cooler onto an AMD AM2/K8 CPU:

1 Slide the metal plate (K) into the slot of

the CPU cooler (between the aluminum

fins and the fan itself).

08-1280_RF-UCPUCF - ENG.fm Page 10 Wednesday, June 11, 2008 3:43 PM
